Agitator seals

SeccoMix 1 SeccoMix 1
  • For top entry drives,
    on request side drive possible
  • Dry-running
  • Single seal
  • Balanced
  • Outboard mounted
  • Multiple springs rotating
  • Independent of direction of rotation
AGSZ AGSZ
  • For top entry drives
  • Double seal
  • Balanced
  • Independent of direction of rotation
  • Gas-lubricated
  • Cartridge unit
ERB ERB
  • Cartridge unit
  • Double seal with integrated bearing
  • Unbalanced
  • Independent of direction of rotation
STD1 STD1 If a STD is employed, it is possible to change seals with the vessel loaded and under pressure (shaft must be stationary!). Installation dimensions according to DIN 28138 Part 1 are possible. Material properties have to be taken into account.
SeccoMix 481 SeccoMix 481
  • For top entry drives
  • For steel vessels acc. to DIN resp. Non-DIN
  • Nitrogen pressurized dual seal, single seal optional
  • Balanced
  • Independent of direction of rotation
  • Multiple springs rotating
  • Dry running
  • Cartridge unit
AGSR AGSR
  • For top, bottom and side entry drives
  • Double seal
  • Balanced
  • Stationary springs on product side
  • Independent of direction of rotation
  • Gas-lubricated
  • Cartridge unit
M481 M481
  • For top entry drives
  • Single or double seals
  • Unbalanced
  • Independent of direction of rotation
  • Multiple springs rotating
  • Liquid-lubricated
  • Cartridge unit
SeccoMix 461 SeccoMix 461
  • For top entry drives
  • For glass-lined vessels acc. to DIN resp. Non-DIN
  • Dry running
  • Nitrogen pressurized dual seal
  • Balanced
  • Multiple springs rotating
  • Independent of direction of rotation
M461 M461
  • For top entry drives
  • For glass-lined vessels
  • Double seal, single seal on request
  • Unbalanced
  • Independent of direction of rotation
  • Multiple springs rotating
  • Liquid-lubricated
  • Cartridge unit
SeccoMix R SeccoMix R
  • For top, side and bottom entry drives
  • Dry running
  • Nitrogen pressurized dual seal
  • Rotating seat at product side
  • Balanced
  • Independent of direction of rotation
MR-D MR-D
  • For top, side and bottom entry drives
  • Seat at product side rotating
  • Unbalanced
  • Liquid-lubricated
  • Double seal
  • Independent of direction of rotation
  • Cartridge unit
  • With or without bearing available
  • Shaft sleeve not in contact with product
AD510 / AD520 AD510 / AD520
  • Dry running
  • Single seal
  • Independent of direction of rotation
HS-D HS-D
  • For top entry drives
  • Double seal
  • Unbalanced
  • Independent of direction of rotation
  • Multiple springs rotating
  • Liquid-lubricated
  • Cartridge unit
HSH-D HSH-D
  • For top entry drives
  • Double seal
  • Balanced
  • Independent of direction of rotation
  • Multiple springs rotating
  • Liquid-lubricated
  • Cartridge unit
HSH(L)U-D HSH(L)U-D
  • For bottom entry drives
  • Double seal
  • Balanced
  • Independent of direction of rotation
  • Multiple springs rotating
  • Liquid-lubricated
  • Cartridge unit
